Highlights
400x - 470x
Optical magnification power
1280 × 1024 pixels
Capture in full detail with resolution up to 1280 × 1024 pixels
USB 2.0
Simple setup
Windows
Fully compatible with Windows XP, Vista, 7, 8, 10 including 32-bit and 64-bit systems.
Annotate & Measure
Use simple tools to draw lines, shapes, and text annotations on the image. Calibrate and measure dimensions including lines, circles, and angles.
Automatic Magnification Reading
Allows the included software to read the magnification setting from the microscope device, simplifying the measuring process.
Two-year warranty & free tech support
All Dino-Lite microscopes feature a two-year warranty and include free U.S. based tech support for the life of the product.
Polarizer
Built-in adjustable polarizer greatly reduces glare on reflective surfaces.
Language options
Software interface defaults to English and can be changed to any of 25 additional translations.
Barcode reader
Software feature to use camera for reading from QR codes and over 20 other types of barcodes.
Working distance & field of view mm| Magnification | 400 | 410 | 420 | 430 | 440 | 450 | 460 | 470 |
|---|
| Working Distance | 5.1 | 6.0 | 7.3 | 8.0 | 8.8 | 10.0 | 11.3 | 11.8 |
|---|
| Field of View | 0.971 x 0.713 | 0.951 x 0.697 | 0.926 x 0.680 | 0.905 x 0.664 | 0.884 x 0.648 | 0.867 x 0.636 | 0.847 x 0.621 | 0.828 x 0.608 |
|---|
| Depth of Field | 0.0261 | | | | | | | 0.0289 |
|---|
Working distance & field of view inch| Magnification | 400 | 410 | 420 | 430 | 440 | 450 | 460 | 470 |
|---|
| Working Distance | 0.201 | 0.236 | 0.287 | 0.315 | 0.346 | 0.394 | 0.445 | 0.465 |
|---|
| Field of View | 0.038 x 0.028 | 0.037 x 0.027 | 0.036 x 0.027 | 0.036 x 0.026 | 0.035 x 0.026 | 0.034 x 0.025 | 0.033 x 0.024 | 0.033 x 0.024 |
|---|
| Depth of Field | 0.001 | | | | | | | 0.001 |
|---|
Specifications
| LEDs | White (8) |
|---|
| Polarization | Yes |
|---|
| Dimensions | 10.5cm (L) x 3.2cm (D) (4.13" x 1.26") |
|---|
| Weight | 105g (3.7 oz) |
|---|
| Cable Length | 182cm (71.65 in) |
|---|
| Magnification Range | 400x - 470x |
|---|
| Working Distance | Standard |
|---|
| Lens Type | Glass |
|---|
| Megapixels | 1.3 MP |
|---|
| Sensor Type | CMOS |
|---|
| Resolution | 1280 × 1024 pixels |
|---|
| Frame Rate (max) | 30 FPS |
|---|
| Image Save Formats (Windows) | BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX |
|---|
| Image Save Formats (Mac OS) | JPEG, PNG |
|---|
| Video Save Formats (Windows) | WMV, FLV, SWF |
|---|
| Video Save Formats (Mac OS) | MOV |
|---|
| Connection Type | USB 2.0 |
|---|
| Included Software | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
|---|
| Imaging Standards | UVC |
|---|
| Flexible LED Control | No |
|---|
| Measurement | Yes |
|---|
| Automatic Magnification Reading | Yes |
|---|
| Extended Depth of Field | No |
|---|
| Enhanced Dynamic Range | No |
|---|
| Magnification Lock | Yes |
|---|
| Body Material | ABS Plastic |
|---|
| Microtouch Sensor | Yes |
|---|
| Package Includes | Microscope, Software CD, Edge Calibration Target, Alternate end caps |
|---|
| Warranty Period | 2 years |
|---|
| Manufactured in | Taiwan |
|---|
